Product Description
Flatbed printer ZX-UV4590 with the highest cost-effective
models, Desktop plate printer
Product Description:
1. LED light curing, max 20000 hours
curing life time
2. Printing size: 450mm*900mm
3. Printing precision: 2880dpi*1440dpi
4. Printing thickness: 100mm
Popular applications:
Promotion items (medals, photo frames,
package printing, leather, customized gifts),
Signage (home decoration), phone and
pad case, garment etc.
|
Model
|
ZX-UV4590
|
|
Print Size(width-length)
|
450mm*900mm(Arbitrary length can be produced
according to
customer requirement)
|
|
Print thickness
|
100mm(you can customize any thickness)
|
|
Ink System
|
6 Color +white
Double
four color
|
|
Print precision
|
2880DPI*1440DPI
|
|
Nozzle Configuration
|
Epson
DX5 (2) 180 nozzle*6 colors, using intelligent transform
ink technology
|
|
Ink drop size
|
Min 3.5 pl ink
|
|
Print Speed
|
Average speed: 7.5 minutes A2 size; max speed:
45 second A2 size
|
|
Power Requirements
|
110-220V, 50-60HZ work 500W, Standby 5W
|
|
Work Environment
|
Working temperature 20-30 ; operating
humidity:20%-80%
|
|
Operating Platform
|
Windows 2000/XP,XPx64, Vistax64, Mac OSX
|
|
Interface Printing
|
USB2.0/1.1 interface and 100 Base-T
Ethernet interface
|
|
Nozzle Cleaning Method
|
Automatic cleaning
|
|
Nozzle Protection Method
|
Infrared automatic protection system
|
|
Print Object Height Detection
|
Intelligent induction, dual detection system
|
|
Weight of Equipment
|
130KG
|
|
Device Dimension(l/w/h)
|
1100*1200*690mm
|
|
Packing Size(l/w/h)
|
1300*1400*890mm
|
