UV2513 Flatbed Printing Machine

Unit Price: FOB 1~100000 USD
Payment Type: T/T,L/C,Western Union
Incoterm: FOB
Min. Order: 1 Piece/Pieces
Delivery Time: 20 Days

Basic Info


Model No.: UV2513


Additional Info


Packaging: wooden case

Productivity: 50 sets/month

Brand: Innovo

Transportation: Ocean

Place of Origin: Zhejiang,China

Supply Ability: 50 sets/month

Certificate: CE


Product Description

1


2


3


4


5


6


7


8

Model

UV2513

UV2513R

Nozzle type

Epson 18600(3.5PL)

Ricoh G4 G5

Number of nozzles

1-2 PCS

6-10 PCS

Printing size

1300*2500 mm

1300*2500 mm

Printing speed

draft mode::36m2/hour

draft mode::72m2/hour

Production mode: 24m2/hour

Production mode: 48m2/hour

High quality mode: 16m2/hour

High quality mode: 32m2/hour

Material

type

Acrylic, aluminum plate, wood, tile, foam board, metal plate, glass, paper and other graphic materials

thickness

120 mm

weight

100 KG

Ink type

EPSON DX5 gray level UV ink 4 color plus white, 6 color plus white (12PL-43PL variable)

Ricoh ink 4 color plus white, 6 colors plus white (7pl-35pl variable)

Technical parameter

Automatic sprinkler cleaning system

Siphon cleaning

Ink supply system

Liquid level automatic sensor

UV lamp

2 LED-UV 200W 20000-30000 hours

Technical support

Protection cover

UV light guide plate to isolate and protect the eyes

Data transfer interface

USB 2.0

RIP software

PHOTOPRINT, MENG TAI, RUI CAI

Image format

TIFF,JPEG,POSTSCRIPT3\EPS\PDF

Color control

Comply with international ICC standards, with curve and density adjustment function

Spray nozzle technology

Drop on-demand , micro piezo inkjet mode

Print mode

Unidirectional and bidirectional

Operating environment

Temperature: 20-28 humidity: 40%-60%

Print resolution

720*360dpi 360*1080dpi 720*720dpi 720*1080dpi 720*1440dpi

Dimension

Machine size

3700mm*2150mm*1260 mm

Packaging size

4100mm*2450mm*1600 mm

Power supply voltage

AC 220V Host maximum 1000W LED-UV lamp maximum 200-400W,Suction motor 1500W

Weight

1250 KG

1400 KG
